Front left studio view of a Z950R ZTrakâ„¢ Zero-Turn Mower

John Deere Z950R

ZTrak™ Zero-Turn Mower

Work faster without compromise. The Z950R ZTrak delivers 12-mph mowing speeds and precise maneuverability, helping you complete more jobs while maintaining the cut quality that sets you apart.

Product Features:

  • 7-Iron™ Pro Mowing Deck
  • Mulch On Demand™ Available
  • Rear Discharge Deck
  • Propane Option Available
View Product Broshure

Specifications

Height-Of-Cut Increments 0.25 in.
Height-Of-Cut Increments 0.64 cm
Cutting Width 60/72 in.
Cutting Width 152/183 cm
Mower Deck Size 54-in. (137-cm) 7Iron™ PRO side-discharge; 60-in. (152-cm) 7Iron™ PRO side-discharge; 72-in. (183-cm) 7Iron™ PRO side-discharge; 60-in. (152-cm) FastBack™ PRO rear-discharge
Height-Of-Cut Range 2.54-14 cm
Height-Of-Cut Range 1-5.5 in.
Discharge Side-discharge, Rear-discharge
Deck Construction 7-Iron™ PRO: 7-gauge, 0.179-in. (4.6-mm) one-piece forged steel; FastBack™ PRO: 7-gauge, 0.179-in. (4.6-mm) fabricated steel

Filter Internal, replaceable
Forward Speed 0-12 mph mph
Forward Speed 0-19.3 km/h km/h
Transmission Hydrostatic
Speed Range 0-19.3 km/h km/h
Speed Direction And Control Twin levers
Speed Range 0-12 mph mph
Hydraulic Capacity 5.9 U.S. qt
Hydraulic Capacity 5.6 L
Reverse Speed 0-7.2 km/h km/h
Reverse Speed 0-4.5 mph mph
Wheel Motors Tuff Torq heavy-duty integrated piston wheel motor with cross porting

Height - With ROPS Up 185 cm
Height - With ROPS Up 73 in.
Weight 1315 - 1423 lb.
Weight 596 - 645 kg
Width - With Chute Down 188, 218 cm
Width - With Chute Down 74, 86 in.
Length 54- or 60-in. deck: 84 in. (213 cm); 72-in. deck: 87 in. (221 cm)
Width - Rear Discharge 161.3 cm
Width - Rear Discharge 63.5 in.
Height - With ROPS Down 47 in.
Height - With ROPS Down 119 cm

Slope Operating Limit 20 degree (angle)
Slope Operating Limit - With Material Collection System 10 degree (angle)
Rollover Protective Structure (ROPS) Yes

Caster Wheels 13x6.5-6
Caster Wheel Type Flat free
Front Anti-Scalp Rollers Left, center, right
Rear Anti-Scalp Rollers 7Iron PRO: Left, center, right; FastBack PRO: Left, right

Park Brake Internal wet disk integrated in the transmission
Dynamic Braking Twin levers
Park Brake Actuation Foot brake

Fuel Type Gasoline
Fuel Tank Capacity 43.5 L
Fuel Tank Capacity 11.5 U.S. gal.
Fuel Tank Switch/Shut-Off Valve No
Fuel Consumption Under normal conditions, load, operation, and dependent on loads and operating conditions 1.1-1.9 U.S. gal./hr (4.2-7.2 L/hr)

Displacement 852 cc
Displacement 52 cu in.
Cooling Forced air, with integrated clean out ports and oil cooler
Pre-Cleaner Yes
Air Cleaner Heavy-duty canister type with safety element
Crankcase Capacity 2.3 L
Engine Power Gross at 3,600 rpm: 27 hp (20.1 kW)
Crankcase Capacity 2.4 U.S. qt
Oil Filter Full flow, replaceable
Lubrication Full pressure
Cylinders 2
Engine Manufacturer/Model FX850V

Load Rating 4 PR
Drive Wheels 24x12-12

Date Collected 2024-08-01T00:00:00

Number 3
Blade Tip Speed 7Iron PRO: Approximately 18,500 fpm; 60-in. (152-cm) FastBack: Approximately 16,500 fpm
Thickness 7Iron PRO: 0.25 in. (6.4 mm); FastBack PRO: 0.31 in. (8 mm)
Length Varies by deck size

Type Electro-magnetic, 225 lb-ft (305 Nm)
Drive V-belt

Operator Presence Starting System Brake-N-Go (foot)
Battery Voltage 12 V
Hour Meter Standard, digital
Cold Cranking Amp 300 amp
Charge System 30 amp

Warranty 36 months or 1500 hours, whichever comes first; First 24 months, no hour limitation
