John Deere XUV825M S4

Crossover Utility Vehicle

Bring the whole crew along with the Gator XUV825M S4 Utility Vehicle. With seating for four and versatile capability, it handles both work tasks and weekend adventures with ease. Built for those who need a vehicle that works as hard as they play.

Product Features:

50-hp (37.3-kW) 3-Cylinder 812-cc Dual-Overhead Cam EFI Engine
Two-Speed CVT Transaxle with 4-Wheel Drive and Rear Differential Lock
Maxxis® Bighorn® 2.0 Extreme Terrain Radial Tires ^ⓘ
Fully-Independent Adjustable Suspension with up to 9-in. (229-mm) of Travel

View Product Broshure

Features

Bring the whole crew along with the Gator™ XUV825M S4 Utility Vehicle. With seating for four and versatile capability, it handles both work tasks and weekend adventures with ease. Built for those who need a vehicle that works as hard as they play.

50-hp (37.3-kW) 3-Cylinder 812-cc Dual-Overhead Cam EFI Engine

Two-Speed CVT Transaxle with 4-Wheel Drive and Rear Differential Lock

Maxxis® Bighorn® 2.0 Extreme Terrain Radial Tires

Fully-Independent Adjustable Suspension with up to 9-in. (229-mm) of Travel

Benefits

Rear right view of an XUV825M S4 Gator with operator loading the cargo box with hay bales in a barn

Haul More in Fewer Trips

Haul up to 1000 lb. (454 kg) in the 16.4-cu ft (460-L) cargo box which can be converted to a flatbed to haul irregular cargo. An optional power lift raises the cargo box with the press of a button. Tow up to 1500 lb. (680 kg) with the included receiver hitch.

Two hi-vis-shirted operators are turning around in the seats of an XUV825M S4 4x4 Gator, laughing at a third person unloading a weedwhacker from the cargo box.

Room for You, and Your Crew

Front and rear bench seats accommodate four with room to spare. Digital display panel includes speedometer, fuel gauge, and hour-meter. Engage 4-wheel drive and differential lock with dash-mounted switches. Cup holders and dash-mounted 12-V outlet are included. Store gear in the large glove box and rear under-seat storage. In lieu of rear passengers, the rear seat folds forward, providing additional cargo space.

man working with a smart phone and tablet

Optional AMS Integration and JDLink™ Modem Attachments

The optional AMS integration kit provides everything needed to mount your StarFire™ receiver and GreenStar™ display for boundary mapping, flagging field obstacles, and soil sampling. Install an optional JDLink™ modem and track your vehicle in the John Deere Operations Center with your fleet. Use the Machine Analyzer tool to review usage data and identify causes of low productivity.

Specifications

Tread Centers	1304 mm
Fuel Capacity	27.6 L
Cargo Box Volume	460 L
Weight	968 kg
Cargo Box Dimensions	45 x 12 x 52 in.
Cargo Box Volume	16.4 cu ft
Hitch	Standard receiver: 2 in. (5.1 cm)
Ground Clearance	279 mm
Height	74.9 in.
Wheelbase	114.5 in.
Ground Clearance	11 in.
Width	1589 mm
Cargo Box Capacity (Weight)	454 kg
Towing Capacity	680 kg
Payload Capacity	1266 lb.
Length	3911 mm
Tread Centers	51.3 in.
Wheelbase	2908 mm
Height	1903 mm
Fuel Capacity	7.3 U.S. gal.
Weight	2134 lb.
Cargo Box Dimensions	1143 x 305 x 1320 mm
Width	62.6 in.
Cargo Box Capacity (Weight)	1000 lb.
Towing Capacity	1500 lb.
Payload Capacity	574 kg
Length	154 in.

Battery	480 CCA
Alternator	85 amp
Color	Green and yellow, TrueTimber® KANATI® camo, olive and black
Power Steering	Yes
Battery	12 V
Instrumentation	Digital display (gear position, system diagnostic light, speed, rpm, 4WD indicator, rear differential indicator, fuel level, coolant temperature, hour meter, miles, and service interval warning light)
Storage	Total: 11.9 gal. (45.1 L); Front console tray with two cup holders: 0.2 gal. (0.9 L); Rear console tray with two cup holders: 0.3 gal. (1.0 L); Glove box: 2.0 gal. (7.6 L); Under rear seat: 7.9 gal. (29.8 L); Under hood: 1.5 gal. (5.8 L)
Power Port - DC Outlet	12 V
Seating	Black vinyl front and rear bench (four-passenger)

Park Brake	Park in-transmission; Optional factory-installed secondary foot operated with hand release
Type	Front/rear hydraulic disc with twin piston front calipers

Cooling System	Liquid
Displacement	812 cc
Displacement	49.6 cu in.
Engine Power	50 hp
Engine Power	37.3 kW
Engine Type	4-cycle gas, electronic fuel injection (EFI)

Rear	27x11-R14 Maxxis® Bighorn® 2.0 extreme terrain radials on steel or alloy wheels
Front	27x9-R14 Maxxis® Bighorn® 2.0 extreme terrain radials on steel or alloy wheels

Date Collected	2025-06-11T11:12:00
Country Of Manufacture	U.S.

Rear Suspension	Fully independent dual A-arm with adjustable coils and sway bar; 229 mm (9 in.) of travel
Front Suspension	Fully independent dual A-arm with adjustable coils; 203 mm (8 in.) of travel

Four Wheel Drive	Dash switch actuated four-wheel drive system
Transmission	Continuously Variable Transmission (CVT) with clutch enclosure
Final Drive	Park, high, low, neutral, reverse transaxle
Traction Assist	Limited slip front differential; Positive locking, switch actuated rear differential lock
Descent Control	Yes
