John Deere 7R 210
Tractor
When handling planting, light tillage, and transport tasks, the 7R 210 delivers responsive power and maneuverabilitysupporting consistent implement performance, efficient field coverage, and controlled operation across varied field conditions.
Product Features:
- Engine hp: 231 Max / 210 Rated
ⓘ - Fully Integrated Precision Ag Technology
- Choice of e23™ Powershift or Infinitely Variable Transmission (IVT™)
- Adjustable Cab Suspension Provides a Smoother, More Comfortable Ride
Features
When handling planting, light tillage, and transport tasks, the 7R 210 delivers responsive power and maneuverability—supporting consistent implement performance, efficient field coverage, and controlled operation across varied field conditions.
Engine hp: 231 Max / 210 Rated
Fully Integrated Precision Ag Technology
Choice of e23™ Powershift or Infinitely Variable Transmission (IVT™)
Adjustable Cab Suspension Provides a Smoother, More Comfortable Ride
Benefits
Run Big Acres with Confidence
When the day calls for heavy draft work, PTO power, or road runs between fields, 7 Series tractors deliver the muscle and efficiency to keep you moving. Strong power-to-weight, transmission choices, and smart power management help maintain speed under load - so you cover more acres with fewer compromises.
Turn Every Pass into Better Decisions
Don’t let performance stop at the cab. With connectivity and documentation through John Deere Operations Center, 7 Series tractors help you track work, verify coverage, and stay on schedule - whether you’re in the field or back at the office. Turn trusted machine data into better decisions and smoother seasons ahead.
Stay Comfortable and In Control All Day
Long days get easier when the tractor fits the operator. 7 Series tractors pair an automotive-inspired cab with comfort options and intuitive controls, so steering, shifting, and implement functions stay at your fingertips. The result is less fatigue, better control, and consistent job quality from first pass to last.
Specifications
| Rated PTO Power | 170 hp |
| Rated PTO Power | 126 kW |
| Engine rpm at Rated PTO Speeds (540E/1000/1.000E) | 1750 |
| PTO Category | Independent; Standard: 44.45 mm (1.75 in.) 20-spline, 1,000 rpm; Optional: 44.45 mm (1.75 in.), 20-spline, 1,000 rpm capable of 35 mm (1.375 in.) 540/1000 rpm; 44.45 mm (1.75 in.) 20-spline, 1,000 rpm with 35 mm (1.375 in.) 540E/1000/1000E rpm gearcase; 44.45 mm (1.75 in.) 20-spline, 1,000 rpm with 35 mm (1.375 in.) 540/540E/1000 rpm gearcase |
| Engine rpm at Rated PTO Speeds (540/1.000) | 1950 |
| Rated PTO Power | 172 PS |
| Engagement Method | Electric switch with adjustable modulation |
| Number of Splines | 20 |
| Available Flow at a Single Rear SCV | 35 gpm (132 L/min) |
| Available Flow at Front SCVs | 33 gpm |
| Available Flow at Front SCVs | 126 L/min |
| Number of Rear Selective Control Valves (SCVs) | Standard: Four SCVs; Optional: Three to five ISO couplers: 12.7 mm (1/2 in.); Five ISO couplers (SCV 1-5: 12.7-mm [1/2-in.] coupler) |
| SCV Control | Electronic |
| Pump Rated Output | Standard: 63 cc: 162 L/min (43 gpm); Optional: 85 cc: 222.3 L/min (59 gpm) |
| Hydraulic System Type | Closed-center, pressure/flow compensated system with load sensing |
| Maximum Engine Power |
231 PS
(hp ISO) |
| Engine Make | John Deere |
| Engine Torque at Rated Speed | 983 Nm |
| Torque Rise | 40 % |
| Maximum Engine Power |
228 hp
(hp SAE) |
| Engine Family | MJDXL06.8309 |
| Rated Engine Power | 154 kW |
| Displacement | 6.8 L |
| Cylinder Liners | Wet-sleeve cylinder liners |
| Rated Engine Speed | 2100 rpm |
| Maximum Engine Torque | At 1600 rpm: 983 Nm (725 lb-ft) |
| Engine Torque at Rated Speed | 725 lb-ft |
| Fuel Type | Diesel |
| Rated Engine Power |
210 PS
(hp ISO) |
| Aftertreatment Type | Diesel oxidation catalyst (DOC)/diesel particulate filter (DPF) |
| Displacement | 415 cu in. |
| Emissions Certifications | Final Tier 4 |
| Aspiration | Single turbocharger, variable geometry turbo |
| Maximum Engine Power | 170 kW |
| Rated Engine Power |
207 hp
(hp SAE) |
| Number of Cylinders | 6 |
| Intelligent Power Management (IPM) | Power boost: 29.6 hp / 22.1 kW / 30 PS (hp ISO) |
| Wheelbase | 115.2 in. |
| Wheelbase | 2925 mm |
| Overall Length | 5520 mm |
| Overall Length | 217 in. |
| Base Machine Weight | 23000 lb. |
| Base Machine Weight | 10000 kg |
| Drawbar Ground Clearance | 360 mm |
| Maximum Ballast Level | 145 lb. |
| Drawbar Ground Clearance | 14.2 in. |
| Maximum Ballast Level | 65 kg |
| Battery Cold Cranking Amps | 1900 CCA |
| Alternator Capacity | Standard: 210 amp, Optional: 250 amp |
| Battery Voltage | 12 V |
| Driving Lights | Standard: 65-W halogen; Available: LED |
| Battery Capacity | 2 x 950 CCA |
| Working Lights | Standard: 18 halogen; Available: 18 light-emitting diode (LED) and two halogen or 22 LED and two halogen |
| Rear Hitch Category (SAE Designation) | Standard: Category 3/3N with Quik-Coupler; Optional: Category 3/3N with hook ends |
| Maximum Lift Capacity Directly at Coupling Points | Standard (Category 3): 5443 kg (12,000 lb); Optional (Category 3N): 6894 kg (15,200 lb); Standard (Category 3 with hook ends): 5443 kg, Optional (Category 3 with hook ends): 6894 kg (15,000 lb) |
| Sensing Type | Electrohydraulic |
| Inner Cab Volume | 3.24 m³ |
| Inner Cab Volume | 114 cu ft |
| Instructional Seat | Standard |
| Primary Display | G5 - 12.8 in. (32.5 cm) |
| Cab Glass Area | 6.56 m² |
| Cab Glass Area | 70.61 sq ft |
| Seat Suspension | Air seat (Standard), ActiveSeat™ II (Optional) |
| Degree of Seat Swivel, Left Hand | 25 degree (angle) |
| Cab Suspension | Adjustable cab suspension (Optional) |
| Degree of Seat Swivel, Right Hand | 40 degree (angle) |
| Radio | AM/FM stereo with weatherband, remote controls, auxiliary input jack, four speakers and external antenna |
| Maximum Speed Forward | 31 mph (50 km/h) |
| Transmission Type | John Deere e23™ 42 km/h (26 mph); Optional: John Deere e23™ Transmission 50 km/h (31 mph), John Deere Infinitely Variable Transmission (IVT™) 0.050-42 km/h (0.030-26 mph), John Deere Infinitely Variable Transmission (IVT) 0.050-50 km/h (0.030- 31 mph) |
| Minimum Speed Forward | 0.03 mph (0.050 km/h) |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 6.9 gal. |
| Diesel Exhaust Fluid (DEF) Tank Capacity | 26.2 L |
| Transmission - Hydraulic System | 160 L |
| Transmission - Hydraulic System | 42.3 gal. |
| Fuel Tank Capacity | 463 (e23™), 513 (IVT™) L |
| Fuel Tank Capacity | 122 (e23™), 135 (IVT™) gal. |
| Crankcase Oil Volume | 26 L |
| Crankcase Oil Volume | 6.9 gal. |
| Cooling System Capacity | 39.5 L |
| Cooling System Capacity | 10.4 gal. |
| Drawbar Category | Category 3; Optional: Category 3 with heavy-duty support; Category 4 |
| Maximum Vertical Load | Standard: Category 3: 1,837 kg (4,050 lb); Optional: Category 3 with heavy-duty support: 4,536 kg (10,000 lb) |
| Remote Diagnostics | ServiceADVISOR™ Remote: available with JDLink hardware and activations; Remote Display Access: available with JDLink hardware and activations |
| Connectivity | JDLink™ |
| Guidance | Integrated AutoTrac™ |
| Date Collected | 4/3/2025 12:00:00 AM |
| Country of Manufacture | USA |
| Wheel or Track Configuration | Wheel |
| Rear Tires Size | RCI Group 47/48 |
| Lift Capacity Through Full Lift Range at Coupling Points | 6740 lb. |
| Lift Capacity Through Full Lift Range at Coupling Points | 3060 kg |
| Number of Front Selective Control Valves (SCVs) | One with front hitch |
| Electric Power | Seven-pin connector |
| Front Hitch Category | Category 3N, ground engaging |
| Engine rpm (at Rated PTO Speeds) | 1940 rpm |
| Front PTO Rotation | Counter-clockwise |
| Front Number of Splines | 21 |
| PTO Speed | 1000 |
| Rear Axle Type | Standard: Rack-and-pinion or flange axles; Optional: Diameter: 100 x 3010 mm (3.94 x 118.5 in.); Diameter: 100 x 2808 mm (3.94 x 110.5 in.); Diameter: 100 x 2550 mm (3.94 x 100.4 in.); Flanged Axle: 335 mm (13.2 in.) |
| Rear Differential Lock | Full-locking electrohydraulic |
| Final Drive | Inboard planetary three pinion |
| Front Axle Differential Lock | 1150 Series MFWD: Limited slip; TLS: Limited slip; TLS with front brakes: Full-locking electrohydraulic (actuated at same time as rear diff lock) |
| Front Axle Type | Standard: 1150 Series MFWD: tread range 1524 to 2235 mm (60 to 88 in.); Optional: TLS: Tread range 1524 to 2235 mm; TLS with front brakes available with 40 km/h (24.9 mph); TLS with front brakes standard with 50 km/h (31 mph) |
| Steering Type | Hydraulic power-steering with electric pump back-up; Optional: ActiveCommand Steering 2 (ACS2) w/ electronic back-up pump |
