John Deere 2030A

ProGator™ Utility Vehicle

Whatever the task, a Gator Utility Vehicle gets it done. These versatile machines are built to haul and tow the heaviest of loads, and with available attachments ranging from top dressers to sprayers, they're your fleet's indispensable sidekick.

Product Features:

  • Powerful 23.9-hp Diesel Engine
  • Efficient Top Speed: 19.1 mph
  • Strong, Durable 7-Gauge Steel Frame
  • 5-Speed Synchromesh Transmission
View Product Broshure

Specifications

Size, Amp 55 amp

Transmission Configuration Five-speed synchro-mesh with five forward gears and one reverse gear
4WD Options Manual engage on demand
Maximum Speed (Standard Tires) 30.7 km/h
Maximum Speed (Standard Tires) 19.1 mph
Manufacturer Kanzaki

Wheelbase 66 in.
Ground Clearance (Unloaded) 168 mm
Length, Overall With Box 328.5 cm
Length, Overall Without Box 125.7 in.
Wheel Tread, Front 123.2 cm
Bed Height (Loaded) 832 mm
Length, Overall (Standard Tires) 319.2 cm
Height, Overall 76.25 in.
Wheel Tread, Rear Standard 129 cm
Width, Overall (Standard Tires) 158.6 cm
Wheelbase 167.6 cm
Ground Clearance (Unloaded) 6.6 in.
Length, Overall With Box 129.3 in.
Length, Overall Without Box 319.2 cm
Wheel Tread, Front 48.5 in.
Bed Height (Loaded) 32.75 in.
Length, Overall (Standard Tires) 125.7 in.
Height, Overall 193.6 cm
Wheel Tread, Rear Standard 50.8 in.
Width, Overall (Standard Tires) 62.4 in.

Fuel Capacity 30.3 L
Cargo Box Internal Dimensions - Height 10.5 in.
Cargo Box Internal Dimensions - Width 128.3 cm
2WD With Standard Suspension 2449 kg
Maximum Gross Vehicle Weight - 4WD With Heavy-Duty Suspension, Wide Rear Tire, And Four-Post ROPS 6264 lb.
2WD With Heavy-Duty Suspension, Wide Rear Tire, And Four-Post ROPS 2841 kg
4WD With Standard Suspension 2449 kg
Cargo Box Internal Dimensions - Length 165 cm
Towing Capacity (Rear Hitch) 1500 lb.
Fuel Capacity 8 U.S. gal.
Cargo Box Internal Dimensions - Height 26.7 cm
2WD With Standard Suspension 5400 lb.
Cargo Box Internal Dimensions - Width 50.5 in.
Maximum Gross Vehicle Weight - 4WD With Heavy-Duty Suspension, Wide Rear Tire, And Four-Post ROPS 2841 kg
2WD With Heavy-Duty Suspension, Wide Rear Tire, And Four-Post ROPS 6264 lb.
4WD With Standard Suspension 5400 lb.
Cargo Box Internal Dimensions - Length 65 in.
Towing Capacity (Rear Hitch) 680.4 kg

Type CARB ASME B56.8a-1994, OSHA12928.51CSA

Battery Voltage 12 V
Battery Cold Crank Amps 500 CCA

Type 4-wheel hydraulic drum

Front Standard 23x10.50-12 (4 PR)
Wide Rear Tire Option 26x14.00-12 (4 PR)
Rear Standard 26x12.00-12 (4 PR)

Attachments Installed Cargo box
At Operator's Ear 86 dBA
Measuring Standard ISO 11201

Turning Circle Clearance - Inside Diameter - 4WD - Radius 69 in.
Turning Circle Clearance - Inside Diameter - 4WD - Radius 1752 mm
Turning Circle Clearance - Inside Diameter - 2WD - Radius 431.8 mm
Turning Circle Clearance - Inside Diameter - 2WD - Radius 17 in.

Front Dual leaf springs and shocks
Rear Dual leaf springs and shocks

High Idle Speed 3450 rpm
Configuration 3-cylinder liquid-cooled diesel
Displacement 1267 cc
Horsepower 17.8 kW
Displacement 77.3 cu in.
Horsepower 23.9 hp

Type Hydraulic power
