Studio image with a front left view of an HPX615E Utility Vehicle

John Deere HPX615E

Work Series Utility Vehicle

Handle challenging terrain and demanding tasks with the GATOR HPX615E Utility Vehicle. Rugged durability and versatile cargo handling help you move materials, haul equipment, and get work done across your property.

Product Features:

20-hp (15.7-kW) 617-cc V-Twin Engine
Two-Speed CVT Transaxle with 4-Wheel Drive and Rear Differential Lock
Turf, All-Purpose, or All-Terrain Tires
Fully-Independent Front and Semi-Independent Rear Suspension

View Product Broshure

Features

Handle challenging terrain and demanding tasks with the Gator™ HPX615E Utility Vehicle. Rugged durability and versatile cargo handling help you move materials, haul equipment, and get work done across your property.

20-hp (15.7-kW) 617-cc V-Twin Engine

Two-Speed CVT Transaxle with 4-Wheel Drive and Rear Differential Lock

Turf, All-Purpose, or All-Terrain Tires

Fully-Independent Front and Semi-Independent Rear Suspension

Benefits

Two white-helmeted landscapers working around an HPX615E Gator loaded with sand on a tree-lined jobsite.

Haul More in Fewer Trips

Haul up to 1000 lb. (454 kg) in the 16.4-cu ft (460-L) cargo box which can be converted to a flatbed to haul irregular cargo. An optional power lift raises the cargo box with the press of a button. Tow up to 1300 lb. (590 kg) with the included receiver hitch.

Side left view of two landscapers in an HPX615E Work Utility Vehicle with rakes, shears, and other tools visible in the cargo box

Comfort and Convenience Standard

Side-by-side bench seating for two with shift lever conveniently located between the seats. Digital display panel includes speedometer, fuel gauge, and hour-meter. Engage 4-wheel drive and differential lock with dash-mounted switches. Cup holders and dash-mounted 12-V outlet are included. A large glove box conveniently stores tools.

man working with a smart phone and tablet

Optional AMS Integration and JDLink™ Modem Attachments

The optional AMS integration kit provides everything needed to mount your StarFire™ receiver and GreenStar™ display for boundary mapping, flagging field obstacles, and soil sampling. Install an optional JDLink™ modem and track your vehicle in the John Deere Operations Center with your fleet. Use the Machine Analyzer tool to review usage data and identify causes of low productivity.

Specifications

Fuel Capacity	27.6 L
Weight	710 kg
Cargo Box Dimensions	45 x 12 x 52 in.
Tread Centers - Rear	48 in.
Tread Centers - Front	49.5 in.
Hitch	Standard receiver: 5.1 cm 2 in.
Ground Clearance	152 mm
Tread Centers - Front	1257 mm
Height	73.5 in.
Wheelbase	75.2 in.
Ground Clearance	6 in.
Width	1486 mm
Cargo Box Capacity (Weight)	454 kg
Towing Capacity	590 kg
Payload Capacity	1400 lb.
Length	3022 mm
Wheelbase	1910 mm
Height	1867 mm
Fuel Capacity	7.3 U.S. gal.
Weight	1566 lb.
Cargo Box Dimensions	1143 x 305 x 1320 mm
Width	58.5 in.
Tread Centers - Rear	1219 mm
Cargo Box Capacity (Weight)	1000 lb.
Towing Capacity	1300 lb.
Payload Capacity	635 kg
Length	119 in.

Battery	480 CCA
Alternator	40 amp
Color	Green/yellow
Power Steering	No
Battery	12 V
Storage	Cup holders, glove box
Power Port - DC Outlet	12 V
Seating	Black vinyl bench

Park Brake	Optional factory installed, hand operated
Type	Hydraulic disc brakes

Cooling System	Liquid
Displacement	617 cc
Displacement	37.6 cu in.
Engine Power	20 hp
Engine Power	15.7 kW
Engine Type	2-cylinder, 4-cycle gas

Rear	24 x 10.5-10
Front	24 x 9.5-10

Date Collected	2022-06-08T11:06:00
Country Of Manufacture	U.S.

Rear Suspension	Coil-over shock
Front Suspension	Independent with McPherson strut

Four Wheel Drive	Dash switch actuated four-wheel drive system
Transmission	Continuously Variable Transmission (CVT)
Final Drive	Park, high, low, neutral, reverse transaxle
Traction Assist	Limited slip front differential, Positive locking, switch actuated rear differential lock
Descent Control	No
