John Deere 3043D

Compact Tractor

Count on the 3043D Compact Tractor for dependable power. Move between tasks efficiently, while simple operation helps you stay productive. Easy to operate and built to perform.

Product Features:

4WD for Maximum Traction
Heavy-Duty Drive Train With a Gear Drive Transmission 8F/8R
Maximum Versatility With Category 1 3-Point Hitch
Efficient Operation With High-Capacity Hydraulic System

View Product Broshure

Features

Count on the 3043D Compact Tractor for dependable power. Move between tasks efficiently, while simple operation helps you stay productive. Easy to operate and built to perform.

4WD for Maximum Traction

Heavy-Duty Drive Train With a Gear Drive Transmission 8F/8R

Maximum Versatility With Category 1 3-Point Hitch

Efficient Operation With High-Capacity Hydraulic System

Benefits

Optional Two-Spool Rear Selective Control Valve (SCV)

3D Series Tractors can be upgraded with a rear hydraulic remote kit that adds two independent hydraulic spools, enabling compatibility with various rear attachments like angled blades and snow blowers. The first spool includes a float position for better landscape contouring and grading precision.

Top studio view of a 3-series compact utility tractor's clean, simple operator's station (seat, steering wheel, arms, back of front tires)

Clean and Simple Operator Station

The 3D operator station is designed to keep operation comfortable, simple, and intuitive throughout the workday. An easy step‑through layout and thoughtfully placed controls support confident operation and reduce unnecessary effort when getting on and off. The clean, practical design helps you stay focused on the task at hand without added complexity.

Rear right view of a 3025D Tractor in an orchard with an operator in a red shirt reaching toward the rear box attachment

Optional iMatch™ Quick-Hitch Feature

John Deere’s iMatch™ Quick-Hitch simplifies implement attachment by ensuring a guaranteed fit for all ASABE Category 1-compatible tools, using included bushings to align implement pins with hitch hooks.

Specifications

Engine Model	3TNV86CT-KJPT
Air Cleaner Type	Dual element
Rated Engine Power	31 kW
Lubrication	Pressurized
Cylinder Liners	Cast-in-block
Rated Engine Speed	2800 rpm
Compression Ratio	19.1:1
Rated Engine Power	42 PS
Fuel Type	Diesel
Displacement	96 cu in.
Aspiration	Turbocharged
Emissions Certifications	Final Tier 4
Cooling System Type	Liquid
Rated Engine Power	42 hp (SAE J1995)
Number of Cylinders	3

Number of Rear Selective Control Valves (SCVs)	2
Hydraulic System Type	Open center

PTO Clutch	Transmission
Brake (For Mid and Rear PTO)	Wet disk
PTO Category	540 rpm
Engine rpm at Rated PTO Speeds (540/1.000)	2400
Engagement Method	Mechanical

Final Drive	Spur gear

Wheel or Track Configuration	Wheel
Drive Type	4WD

Front Tires Size	R1 Bar: 7-14; R3 Turf: 27x8.5-15; R4 Industrial: 25x8.5-14

Primary Brakes	Wet disk

Draft Control Sensing	Position control

Alternator Capacity	55 amp

Gearshift Location	Right-hand side

Cruise Control	No
Creeper	No
